SimR Tutorial

Anthony J. Clark

2026-06-01

QR code for pre-survey

Introduction

Questions

QR code for Google Sheet

SimR

Simulation in Robotics

  • What simulator should I use?

  • That question is common in robotics research, robot learning, planning, control, and deployment.

  • The harder question is usually:

    What simulator should I use for this robot, this task, and this research question?

At ICRA 2026

Advise

  • Stick with whatever makes you productive (or happy).
  • MuJoCo (with MJWarp) is pretty stable.
  • Isaac Sim has a lot of features.
  • URDF is ubiquitous.
  • This tutorial
    • Newton Physics
    • USD (and URDF)
    • Viser Viewer

About Me

I am a professor in the Computer Science Department at Pomona College in Southern California, USA.

I learned a lot about simulation the hard way; you shouldn’t have to.

My Simulation Problem

I’ve spent arguably too much time trying different simulation methods and tools:

  • Player stage, Webots, Gazebo, etc.
  • Simulink/MATLAB, Julia, SimPy, FEA
  • ODE, Bullet, DART, Box2D, Chrono, MuJoCo
  • SAPIEN, ManiSkill, Newton Physics
  • Gazebo, Webots
  • Unreal, Unity, Godot
  • custom simulators
  • and many more

At ICRA, there are always several more that I will be tempted to explore.

Simulation in Robotics

  1. Have some idea of a physical device
  2. Create a simulation
  3. Run system identification and calibration experiments
  4. Optimize and experiment in simulation
  5. Transfer to the real world
  6. Back to previous steps…

Robotics Simulation

Developing Simulation

Robotics Simulation

Simulation is the use of a model to study, predict, test, train, or evaluate the behavior of a robot or robotic system.

In robotics, simulation is used for:

  • prototyping
  • control design
  • planning

Robotics Simulation (cont.)

  • robot learning
  • perception
  • benchmarking
  • regression testing
  • sim-to-real transfer
  • hardware/software integration
  • safety and failure analysis

Simulation Is Not One Thing

A simulator may model:

  • robot kinematics
  • rigid-body dynamics
  • contacts and friction
  • actuators and transmissions

Simulation Is Not One Thing (cont.)

  • sensors and perception
  • lighting and rendering
  • terrain, fluids, or deformable objects
  • communication and latency
  • uncertainty and noise
  • humans, objects, or other robots

The right simulator depends on which of these matter for your question.

Research Questions (1/2)

Robotics simulation supports application-focused questions:

  • How can we train a robot policy safely and efficiently?
  • How can we evaluate a controller before deploying it?
  • How can we test a planner across many environments?
  • How can we compare methods under controlled conditions?
  • How can we identify likely failure modes before hardware testing?

Research Questions (2/2)

Robotics simulation also supports method-focused questions:

  • How accurate does the simulation need to be?
  • Which modeling assumptions matter?
  • What transfers from simulation to reality?
  • How should we randomize or calibrate the simulator?
  • How do we make simulated experiments reproducible?
  • How do we avoid overfitting to a simulator?

Terminology

Engine World Body Shape Joint
urdf World Link Geometry Joint
DART 1 World Skeleton Shape Joint
MuJoCo World Body Geom Joint
Newton Physics World/Model Link Shape Joint
USD 2 Stage Prim Geometry Joint
Planck.js World Body Shape Joint
Box2D World Body Shape Joint
ODE World+Space Body Geom Joint
PROJECTCHRONO System Body Shape Link
Bullet World Body Shape Joint

Live Demos

Now let’s see some of these questions in action with live demos.

To the tutorial

A Common Robotics Simulation Loop

flowchart LR
    Model[model robot and environment] --> Sim[simulate]
    Sim --> Eval[evaluate behavior]
    Eval --> Analyze[analyze failures]
    Analyze --> Improve[improve model, controller, planner, or policy]
    Improve --> Sim
    Eval --> Deploy{deploy?}
    Deploy --No--> Improve
    Deploy --Yes--> Real[test on hardware]
    Real --> Compare[compare sim and real]
    Compare --> Improve

A Common Experiment Loop

config = load_config()
sim = make_simulator(config)
robot = load_robot_model(config)
task = load_task(config)
policy = load_policy(config)

for seed in seeds:
    env = make_environment(sim, robot, task, seed)

    for episode in range(num_episodes):
        trajectory = rollout(env, policy)
        result = evaluate(trajectory, task)

        save_result(seed, episode, result)
        save_trajectory(seed, episode, trajectory)

summary = analyze_results()
make_plots(summary)

if ready_for_hardware(summary):
    run_real_robot_experiment(policy)

Optimization and Learning Loop

Some robotics projects use optimization, reinforcement learning, imitation learning, or evolutionary search.

flowchart LR
    Init[initialize policy, controller, or design] --> Eval[evaluate in simulation]
    Eval --> Stop{stop?}
    Stop --Yes--> Retn[return best candidate]
    Stop --No--> Update[update candidate]
    Update --> Eval

Python Interface Sketch

Observation = list[float]
Action = list[float]
Trajectory = list[tuple[Observation, Action]]
Metrics = dict[str, float]
Policy = object

def make_simulator(config): ...
def load_robot_model(config): ...
def reset_environment(seed: int): ...
def policy(obs: Observation) -> Action: ...
def rollout(env, policy: Policy) -> Trajectory: ...
def evaluate(trajectory: Trajectory) -> Metrics: ...

Simulation

This section and the related demos are the focus of this tutorial.

Types of Simulation

  • Analytical or closed-form dynamics
  • Numerical dynamics
  • Rigid-body dynamics
  • Contact and friction simulation
  • Sensor simulation
  • Rendering and perception simulation
  • Soft-body dynamics
  • Finite-element analysis
  • Digital twins

Common Robotics Simulators

Examples include:

  • Gazebo
  • MuJoCo
  • Drake
  • Webots
  • CoppeliaSim
  • NVIDIA Isaac Sim / Isaac Lab
  • PyBullet / Bullet
  • RaiSim
  • Project Chrono
  • Simscape Multibody
  • Unity- or Unreal-based environments

The goal today is not to declare one winner.

The goal is to understand tradeoffs.

Simulation Advice (1/4)

Choose the correct level of abstraction.

  • What do you care about?
  • Are you studying perception, planning, control, learning, design, or deployment?
  • Do you care about the electro-mechanical properties of the motors?
  • Do you need accurate contact and friction?
  • Do you need actuator saturation, latency, backlash, or compliance?
  • Do you care about vision, depth, LiDAR, tactile sensing, or force sensing?

Simulation Advice (2/4)

Simplify when possible.

  • Can you simplify the robot geometry?
  • Can you approximate the wheels, gripper, or contact surfaces?
  • Can you use kinematics instead of dynamics?
  • Can you use simple rendering instead of photorealistic rendering?
  • Can you approximate hydrodynamics, deformable objects, or terrain?
  • Can you test the algorithm in a toy environment first?

The best simulator is often the simplest simulator that captures the phenomenon you care about.

Simulation Advice (3/4)

Consider your simulation characteristics.

  • Simulation should be noisy enough to expose brittle solutions.
  • Simulation should be deterministic enough to debug.
  • You should evaluate a policy, controller, or planner with multiple initial conditions.
  • Your simulation should usually be faster than real time.
  • Your simulation should be parallelizable.
  • Your simulation should be able to run headless.

Simulation Advice (4/4)

Numerical details matter.

  • Avoid unnecessarily stiff springs.
  • Avoid unrealistic controller gains.
  • Use reasonable masses, lengths, forces, and time steps.
  • Scale your environment to reasonable numerical values.
  • Use fixed time steps when appropriate.
  • Log simulator warnings and instability.
  • Test extreme parameters and edge cases.

The Reality Gap

The main challenge is the reality gap.

Simulation and reality differ because of:

  • simplified dynamics
  • incorrect inertial parameters
  • contact and friction errors
  • unmodeled actuator behavior
  • sensor noise and bias
  • latency
  • calibration errors
  • lighting and rendering differences
  • object and terrain variation
  • wear, damage, and hardware variability

Sim-to-Real Advice

Think about sim-to-real from the beginning.

  • Decide what needs to transfer.
  • Measure physical parameters when possible.
  • Calibrate the simulator with real data.
  • Use domain randomization when appropriate.
  • Randomize initial conditions, object properties, terrain, sensors, and actuation.
  • Prefer robust policies over policies that exploit one narrow simulated setting.
  • Validate intermediate quantities, not just final task success.

Decouple the Pipeline

Decouple simulation, visualization, learning, and evaluation.

  • Make it easy to swap out simulators.
  • Make it easy to swap out controllers, planners, policies, or optimizers.
  • Make it easy to swap out visualization tools.
  • Separate training from evaluation.
  • Separate robot models from task definitions.
  • Separate configuration from source code.

Avoid Simulator Overfitting

Be careful that your system is not too easy to game.

Policies and controllers may exploit:

  • reward bugs
  • termination conditions
  • contact artifacts
  • sensor artifacts
  • unrealistic friction
  • unstable numerical integration
  • privileged simulator information
  • task distributions that are too narrow

If it looks too good, inspect the rollout.

Robotics Experiment Advice (1/3)

Always prototype.

  • Start with the simplest robot, task, and environment.
  • Test controllers with simple benchmark systems.
  • Test planners with simple maps.
  • Test policies in small environments.
  • Test simulations with known behaviors.
  • Test extreme parameters.
  • Add complexity one piece at a time.

Robotics Experiment Advice (2/3)

Save enough information to understand what happened.

  • Save configurations.
  • Save random seeds.
  • Save simulator versions.
  • Save robot models.
  • Save trained policies or controller parameters.
  • Save evaluation results.
  • Save trajectories, logs, and videos when possible.
  • Save failures, not just successes.

Robotics Experiment Advice (3/3)

Plan for reproducibility.

  • Use checkpointing.
  • Use structured output directories.
  • Use configuration files.
  • Track dependencies and software versions.
  • Record hardware information when relevant.
  • Use tools like Weights & Biases, MLflow, Sacred, or simple CSV/JSON logs.
  • Make it possible for future you to rerun the experiment.

Evaluation Advice

Evaluate beyond the training conditions.

  • Use held-out environments.
  • Use held-out objects, terrains, lighting, or initial states.
  • Use multiple random seeds.
  • Report variability.
  • Compare against baselines.
  • Compare against simple hand-designed controllers or planners.
  • Report wall-clock time, sample efficiency, and compute when relevant.

Parallelism (1/3)

Consider your computational resources.

Parallelize across:

  • random seeds
  • training runs
  • evaluation episodes
  • environments
  • policies, controllers, or planners
  • robot designs
  • hyperparameter settings

Parallelism (2/3)

Useful tools include:

Parallelism (3/3)

Rules of thumb:

  • Plan to leave a few cores free for the operating system.
  • Parallelize at the random-seed level when you care about variability.
  • Parallelize at the rollout or environment level when evaluations are expensive.
  • Profile before optimizing.
  • Avoid manual experiment management when possible.
  • Make failed jobs easy to detect and rerun.

Analysis Advice (1/2)

Set up good tools for analysis.

  • Compare your results to a baseline.
  • Try to construct a good solution by hand before training or optimizing one.
  • Use consistent themes for your plots and figures.
  • Plot learning curves, success rates, failure rates, and task metrics.
  • Inspect trajectories and videos.

Analysis Advice (2/2)

For papers and presentations:

  • Use vector graphics over raster graphics for plots when possible.
  • Generate figures for both presentations and articles.
  • Show variability across seeds.
  • Show representative successes and failures.
  • Report the number of environment steps, evaluations, or rollouts.
  • Report compute resources when they affect interpretation.

Communication Advice

Write about your work.

  • Write a small bit every day.
  • Write down a prediction before you run an experiment.
  • Write your article outline before you run your experiments.
  • Write down what would convince you that your approach failed.
  • Keep a list of assumptions and known simulator artifacts.
  • Document surprising failures.

Exemplar

Problem Statement

Let’s start with the following problem statement:

We want to train and evaluate an autonomous wheeled mobile robot to navigate quickly over obstacles and stop in front of a wall.

This is intentionally simple, but it touches many core simulation questions:

  • dynamics
  • sensing
  • control
  • evaluation
  • robustness
  • sim-to-real assumptions

What Can We Vary?

For the robot:

  • wheel radius
  • wheel base
  • mass and inertia
  • motor limits
  • controller gains
  • sensor type and noise

For the environment:

  • obstacle geometry
  • friction
  • wall location
  • starting pose
  • terrain properties
  • lighting or perception conditions

For the algorithm:

  • hand-designed controller
  • planner
  • reinforcement learning policy
  • evolutionary optimization
  • model predictive control

Online Demos

Simulation demos:

Full robotics simulation demo:

Takeaways

  • Simulation is a tool, not a result by itself.
  • Choose the simulator based on the research question.
  • Start simple.
  • Validate assumptions.
  • Watch for simulator artifacts.
  • Design experiments for reproducibility.
  • Think about sim-to-real early.
  • Inspect failures.

Thank you!
