This is a 8 week long final project for the course with weekly milestones. This document is subject to change with each milestone, e.g., offering more details or clarifications or iteration based on class feedback.

For the final project in CST 181DT: computational design tools, you and your group will be creating—you guessed it—a computational design tool. You will choose groups of 4¹ and also a weekly meeting time for at least an hour that everyone can regularly commit to during the duration of this project.

Throughout the way, you will be conducting need finding user interviews for your tool, developing prototypes of various fidelity, user testing your tool with your peers in and outside of class, and writing up your results and motivation in the format of a short “late breaking work” research paper. The learning goals of this project are to gain experience in engineering interactive software and to use the human-centered design process to motivate and evaluate software design decisions.

What counts as a computational design tool?

A computational design tool is a tool that uses computation to allow users to interactively create something. The computational aspects may be simple or complex, the actual act of making may be simple or complex, but the results, or the impact on the process, should have the potential to be meaningful and diverse.

For instance, in increasing implementation difficulty:

• A map where users may place pins and enter text memories of their queer experiences (i.e., Queering the Map). The computational and making aspects are relatively simple (place pins and enter text on a map), but because this is a collaborative tool connected to personal narratives, the resulting map full of pins is diverse and meaningful.
• A drawing program that fades out your past strokes over time. You can implement this relatively easily in Processing by keeping track of the strokes, attaching a timer to each stroke, and removing it from the canvas when the time has expired. But because strokes disappear and disrupt the normal drawing process, this tool has the potential to change how users relate to drawing and how they choose to draw.
• A tool to create black out poetry (i.e., poetry made by crossing out selective words) from Twitter. Users can search a Twitter hashtag, the tool can bring up some subset of tweets and guide the users in rearranging them and blacking out words. This tool has very wide walls and relatively high user agency: the tool makes few decisions, while users are making more of the decisions. Here’s one I found that uses Project Gutenburg!
• An Inkscape extension that, if users highlight and select their laser cut joints, will keep them all at a user entered width of material no matter how they scale or modify the rest of the drawing. (Kind of like Lillicon but specifically for keeping your joints a consistent size.) Requires some effort to figure out how to actually make this possible, a relatively simple interaction, but wide walls: it could take any input. And certainly useful!
• A social media app like BeReal where users are asked at a random time of day to post, but instead of an image it’s a 30 second audio clip. The computational aspects are complex (building a social media platform is a lot of work), the act of making is relatively simple (just record your microphone), but again the results could be interesting and diverse. (You can imagine users can also play back all of their 30 second clips compiled together for a 3.5 minute weekly recap.)

Here are some examples that would not be considered a “design tool” for this project:

• A direct manipulation UI that lets users make Gmail filters through selecting emails and folders, removing the need to code/know how to type the syntax for Gmail filters. (Too narrow walls, not diverse range of results - how is it helping with “design”?)
• Something like Fishdraw that generates artifacts for the user without a lot of input (too automated/users lack interactivity or agency in the design process in that the only interaction is that they press a button).

What are the constraints of this project?

• The tool should be a novel idea. We are not conducting research so it does not need to produce “generalizable” knowledge, but you should not be building something that already exists.
• The tool needs to have a computational solution, i.e., you should be writing code somewhere.
• The user needs to have a meaningful interaction with the tool that results in diverse, user-generated output. (Basically, aim for wide walls.)
• The tool should be codeable in 4-6 weeks.

What are principles we should follow?

• Clarify your users, domain of use, the problem that you’re tackling, and how you’re computationally solve that problem. It’s OK if the problem is something like, “there is no existing tool that does what our tool does”, or “doing what our tool does is hard with existing methods, so we made it easier”.
• Think of inputs and outputs. What is the possible input space of your tool? If your tool was a function, what does it do? What is the possible output space?
• Iterate, iterate, iterate. Iteration is great! Your grade will never be penalized for iterating or pivoting. If your final tool is exactly the same as your initial brainstorm, I will personal be very surprised.

Final deliverables

• The tool itself, to be presented by your group and used by your classmates in a “tool expo” on the last day of class.
• A short (4 page max) written paper for your tool, in the SIGCHI Latex paper template, which, in addition to an abstract/conclusion, includes (1) an introduction, (2) a methods section, (3) an evaluation, and (4) a short future work section. (Basically what you would see in a standard CHI “late breaking work” besides a related work section.)
• A video demonstration of your tool which addresses and demonstrates its floor, ceiling, and walls as well as includes at least 2 intro sentences about the larger motivation, context, or problem you’re addressing with your tool.
• A PDF documentation of your design process. Since the process is so long, this should be a living document that you add to after each team meeting. This differs from the paper in that the paper reports final decisions while the documentation should explain pivots, prototypes, and design rationale. Attach your weekly team meeting notes as an appendix.

---

Timeline

This is a 8 week long project with 6 milestones. Here’s a rough timeline to keep you on track.

• By class 7B: Milestone 1: Ideas. Form groups in class around pitching ideas.
• During class 8B: Start on creating paper prototypes.
• By class 9A: Milestone 2: Needfinding. Conduct needfinding interviews. At this point, you should feel more confident in your project idea.
• By class 10A: Milestone 3: Storyboard & video paper prototype of the tool. We will be evaluating the low fidelity, paper version of the tool in class together.
• By class 10B: Milestone 4: Project introduction. Practice writing up the motivation of your project using the argument formats of a research paper.
• By class 11B: Milestone 5: First Wizard of Oz prototype in Figma. A Wizard of Oz prototype is a higher fidelity prototype that gives an accurate impression of the tool interaction, but is not implemented (e.g., you can be the computer–the Wizard of Oz). We will be conducting an evaluation of your tool prototype in class for feedback and iteration.
• By the Friday after class 12B: Milestone 6: System diagram. At this point you should have a good idea of how to implement your tool. Get engineering!
• Final presentations class 15B (last class of the semester).

---

Milestone 1: Ideas

Due 11:00am Oct 9.

Please submit 3 potential project ideas on this Google form. Timely submission of this assignment counts towards your participation grade in class.

---

Milestone 2: Needfinding

Due 11:59pm Mon, Oct 21. (The 11:59pm deadline is to accomodate the fact that you have personal RRs due before classtime.)

Now that you have your groups, let’s focus on defining and refining your project idea. This milestone has three separate components which should be done in order: (1) Developing a needfinding interview guide as a group, (2) scheduling and conducting an individual 30-60 minute needfinding interview, and (3) coming together as a group to talk about and synthesize the findings. This should result in forming design goals for the tool.

The learning goals of this milestone are to (1) develop experience in conducting good needfinding interviews, such as asking the user to tell stories, and (2) practice analyzing interview data to extract design goals.

Needfinding

Needfinding is an important part of the design process. It will help you both focus your idea and generate possibilities for iteration and innovation. Is your tool addressing a salient problem in its domain? Are there other user needs going unmet that you might additionally, or instead address? How can we discover what users need and want in building a useful (or entertaining, or mischievous–whatever your end goal is) tool? For this milestone, you will be conducting story interviews to generate design insights and goals for your tool. To get to these design goals, first you need to understand what the user needs are in the context of using your tool.

First, develop an interview guide as a team. A semi-structured interview means while you have a general interview guide, it is OK to stray away from the guide and ask spontaneous follow up questions reacting to what your interview participant has said. Some pointers:

• Ask a specific question (“tell me about a time when you…”) to start things off. It may be tempting to ask a more general question to break the ice, but that may bias the participant at talking at a high level of abstraction for the rest of the interview.
• Get participants to be as specific as possible. (Hence why we ask them for stories!)
• Avoid asking yes/no questions. Ask open-ended questions.
• Ask about moments of breakdown (when something did not go as expected), and how participants recovered from that breakdown.
• What kinds of participant data can help you motivate and justify your tool? What questions or unknowns do you have around your idea, or around how your tool should be designed?
• Remember, first talk about the problem you are trying to address in general: avoid mentioning your specific solution. Near the end of the interview it is OK to reveal your tool idea and solicit opinions.
• However, do not pitch your initial tool idea and then ask “would you use it?” Participants may feel biased to answer yes to avoid an awkward social situation. Instead focus on asking open-ended questions; you can ask them, for instance, specific instances of how they would potentially incorporate this tool into their lives.
• For a 30 minute interview, ~10 interview questions should be sufficient. They should be ordered in the order you will ask them. You may also choose to mark questions as skippable or not (do you want an answer to this question for everyone, or is it better to get the juicy details of some tangent the participant went on?).
• After the interview, before leaving, immediately jot down 3 or so surprising impressions or critical points.

Once everyone agrees on the questions, it’s time to ask them!

Resources

Some additional optional readings that may help you in conducting needfinding:

• 10 cognitive biases to avoid in User Research (and how to avoid them)

Second, everyone should conduct their own 30-60 minute long semi-structured interview or contextual inquiry. Your person can be a fellow student, but ideally they should be part of the target user group of your tool. I would recommend scheduling them even before you finalize the interview guide so you can lock in a 30 minute timeslot to conduct the needfinding. Semi-structured interviews may also be conducted in person or online via Zoom. If on Zoom, I highly suggest recording the meeting so you can get an automatically generated text transcript after.

Every team member should turn in a page of takeaways/notes from the interview. Sometimes, or for some individuals, it is hard to carry a conversation and focus on jotting notes at the same time. If this is the case, I highly recommend asking the person for permission to audio record the interview. Conduct the interview with your full attention on getting data and talking with the person, and then listen to the recording afterward to create your note sheet and takeaways. A suggested format of the notesheet is Q/A: copy/paste your questions from your interview guide, and then write the interviewee’s answers after each question. It does not have to be verbatim, but it should capture the main points of what they said.

This notesheet should include:

• who conducted the interview
• who was interviewed and their relationship to the interviewer
• where the interview was conducted (dorm, Zoom, library, etc.)
• the 3 or so first impressions or critical points written down immediately after the interview
• the general summary or Q/A notes from the interview.

The notes should be written in enough detail that your groupmates can understand the interview takeaways.

Finally, the team should get together and talk about and synthesize their findings and create design goals.

The team should share and read everyone else’s interview notes and write a summary paragraph of results. What were common themes throughout all the interviews? What were points of tension or disagreement? What are the most salient needs in your problem or domain area?

Finally, write a bulleted list of the 3 main design goals you want your tool to have a result of these interview findings. Design goals should be borne out of your design decisions in scoping the project and user. How can you address the most salient needs you found from your interviews? What do you prioritize in the tool design, and what do you prioritize it over? What kind of results do you wish to achieve? Are you targeting expressiveness, efficiency, iteration, a new mental model, or something else?

For example, some good design goals are:

• Support reflection-in-action through providing auditory feedback. This has a goal from literature we’ve talked about (reflection-in-action) that the tool wants to support, and specifically says how to achieve that (audio feedback).
• Support learning unfamiliar designs through using templates. Again, a very specific problem (help with learning) and solution (let’s introduce templates so users have a starting point).

Some less good design goals are:

• Make the tool intuitive. What does it mean to be intuitive? Can you be more specific? What does intuitive look like when interacting with your tool?
• Supporting wide walls. Again, too vague: all your tools should support wide walls. How exactly do you imagine your tool to do so?

Resources

Some academic papers that employ this method of needfinding and synthesizing design goals from “formative studies” (or existing literature) that you could read for reference and/or inspiration include:

• Draco - Section “Design Goals”
• Editing Spatial Layouts through Tactile Templates for People with Visual Impairments - Section 3 “Design Imperatives” (this was my first paper in my PhD)
• A Layered Authoring Tool for Stylized 3D animations - Section 3.4 “Design Goals”
• Color Field: Developing Professional Vision by Visualizing the Effects of Color Filters - Section 3.2 “Design Objectives”
• Metaphoria: An Algorithmic Companion for Metaphor Creation - Section 3 “Design Goals”

Deliverables

Submit 1 PDF to Canvas containing:

1. The overall synthesis/summary of the needfinding interviews and 3 design goals
2. Each individual person’s interview notes
3. The shared interview guide

Milestone 3: Task Analysis & Video Prototype

Due 11:00am Mon 10/28.

In class, we began to create a scenario paper prototype of the most salient task users should be able to complete with your tool. Now it’s time to further flesh out your tool by creating a task analysis detailing all possible tasks, and by recording a video prototype of you interacting with the paper prototype across not one, but the three most important tasks/scenarios.

Personas

Before you decide on what tasks your tool should support, it may be helpful to envision the kinds of people who would be likely to use your tool. One common design strategy is to create personas: basically fake people with realistic backstories and realistic goals that will help you concretely imagine users–and thus usage scenarios–for your tool.

For instance, an example persona for our previously mentioned blackout poetry tool could be Maya:

Background: Maya is a 27-year-old based in Los Angeles. With a BS in English, she has a passion for creative writing, though has yet to find success in that as a career (she works a boring spreadsheet desk job to pay the bills). Maya loves to travel over the world for inspiration for her creative practice.

Goals: Maya mainly does blackout poetry to relax as a hobby, but also enjoys being able to reappropriate texts to give them new meaning and new life. She likes sharing her blackout poetry on her IG stories. Because she travels so much, she would like to be able to digitally do black out poetry on her phone on trains, as opposed to at a desk with physical sheets of paper.

Come up with 2 personas for your tool, and try to make them have as different background as possible. For instance, if Maya is a user that is close to your own lived experiences, what about someone who is much older? Someone who is a professional rather than a hobbyist? Try to capture the wide walls of your tool in your personas: your imagined users should span a wide space of usage potential.

Task Analysis

Task analysis is the systematic study of how users complete tasks to achieve their goals. This knowledge ensures products and services are designed to efficiently and appropriately support those goals. - From the Neilsen Norman Group

The goal of this section is to make a hierarchical task analysis diagram. In class, you identified one scenario (also called “task”) for your tool. Now, with your personas in mind, let’s map our all the potential tasks your tool should support.

First, with your personas in mind, create a list of goals users will have when using the tool. Tasks will stem from the goals. For instance, the hierarchical task analysis diagram below shows the tasks (pink, labeled 1-4) necessary for a user to accomplish their goal of making a digital copy of a letter (dark pink, labeled 0). Each task may optionally have further subtasks (labeled 1.1, 1.2, 1.3, etc.) if the task requires many back-and-forth exchanges with the tool.

An example hierarchical task analysis diagram, detailing tasks and subtasks that stem from a goal.

Your task analysis diagram should include the goals, tasks, and necessary subtasks to cover the full scope of your envisioned interaction. The scenario you prototyped in class is probably a task that belongs to a larger goal. For instance, if your scenario was drawing something on a canvas, the user goal would be “create original artwork”, and other tasks towards achieving this goal would be, for example, loading in existing assets and saving the user’s artwork after they’ve drawn it.

In general, your tool should support between 1-4 goals, depending on the scope. Please create a different task analysis diagram for each goal (so if your tool has 3 goals, you would turn in different 3 diagrams, each stemming from a root user goal node). I highly encourage someone from your group to reach out to me to double check your goals before you get started.

You may find this Miro Template helpful to getting started. Make sure goals, tasks, and subtasks are different colors.

Video prototype of the most salient goal

Finally, pick the most important user goal (probably the goal that encapsulates the scenario you chose in class) and create a video prototype. A video prototype is just a recording of a user interacting with your paper prototype, showing the user flow, while someone else replaces the paper screens according to their inputs.

Your video prototype should follow the task flow as detailed in your hierarchical task diagram. You will likely need to create a few more screens compared to your scenario prototype in class to cover all the tasks for your chosen goal. To record this video, I recommend at least 3 people being involved:

• One person as the camera person recording the video
• One person as the user, who points and interacts
• One person as the Wizard-of-Oz “computer”, who switches out sheets of paper depending on user actions

Additionally, someone should verbally describe the high level user goal at the start of the video, and narrate what is happening as you go through the interaction. I do not expect the video to be very long: probably between 1-3 minutes, depending on the complexity of your interaction.

Remember that a video prototype is a recording of a wireframe, not a sketch. Your paper prototype should resemble the fidelity of a wireframe: clearly defined UI elements, showing “real fake” information (i.e., canned inputs/outputs, but realistic to the goal), as opposed to being a more abstract, higher level sketch you would find in a storyboard.

Remember that we are still doing a scenario prototype, so we are not prototyping every single feature in your tool, just the ones necessary to complete your most important user goal. We are also not accommodating “real” inputs yet, so as users advance through the screens, your prototype should just “choose for them” the options.

Creating the video prototype will (1) enable the instructor to give you design feedback on this assignment, and (2) prepare you well for understanding how to run the prototype interaction for your classmates. Please bring your paper prototype to class on Mon 10/28 so your classmates can be the “user” and give you feedback as well!

Reflection paragraph

Since we have stopped PM assignments for now, I would still like to collect feedback on how you’re doing :). Feel free to answer as a group, or individually if there is a disagreement. It’s the usual questions: How long did your group spend on this assignment? Out of the three components (personas, task analysis, video prototype), what felt the most helpful/conductive to your learning and making progress on designing your tool? Were there any unexpected challenges? How is the workload of the class matching to your expectations? How is the workload being distributed among the group and general group dynamic? (If there are serious concerns with group dynamic at any time, feel free to privately message me too.)

Deliverables

Submit 1 PDF to Canvas containing:

1. A brief description of your 2 personas, including their background and goals
2. Your hierarchical task analysis diagram
3. A link to your video prototype (e.g., uploaded on YouTube or Google Drive - make sure it’s viewable to anyone with the link), showing the envisioned interaction for your most salient goal in your task analysis diagram
4. Your reflection paragraph (thanks!)

---

Milestone 4: Introduction Draft

Due 11:59pm Friday 11/1.

Short paper introduction

As part of your final deliverable, we will be writing parts of a short, 4 page paper in the SIGCHI research paper style describing various aspects of your tool. For this assignment, you should write a draft of the introduction section.

First, one person should make a copy of the Overleaf template and invite all other group members to collaborate via email. Unfortunately, Pomona does not provide free Overleaf premium accounts, so you can have 2 collaborators at most. I would recommend you collaborate on the text in a Google Doc and then move it over to Overleaf. It’s important you keep this link since you will be adding to this paper throughout the semester.

If you’re not already familiar, see how to make tables (\begin{table}) and figures (\begin{figure}) in the template, as these will come in handy later.

Work together to edit the template to contain only your introduction to your tool project. As we will see in lecture on Thursday, good introductions are like a funnel: we start with broad context, then introduce our problem, then introduce our solution.

I would recommend first working on establishing a 6 topic sentence outline, and then fleshing the points in the outline into paragraphs. I am happy to take a look at the outline during OH. Let’s run through an example looking at a paper I wrote about a tool that automates the rigging process for character illustrations. The outline should address these 6 points:

• Context: What is the domain you’re working in? Why should people care about this domain? If relevant, how has it evolved over time? Example topic sentence(s):

Illustrated 2D characters are prevalent across many visual applications, including storytelling, advertising, animation, and games. Recently, “mix-and-match” 2D character creation tools have emerged that make character design more accessible to a broader range of users. With mix-and-match tools, users can quickly explore a range of character designs by selecting different combinations of body and accessory layers.

• Problem: What’s the problem you’re solving? Make the reader feel the urgency of the problem, so that by the end of the paragraph they care a lot that someone finds a solution. Example topic sentence(s):

However, this convenience comes at the cost of flexibility and expressiveness. While there are typically dozens of accessories to choose from, there are many fewer body shape and pose variations (often just one).

• Set up the bit: This paragraph usually answers the question, “Why isn’t this problem solved yet?” by setting up the bit that you’re going to flip. The topic sentence typically summarizes existing approaches to solving the problem by articulating the bit that they share, and points out why those approaches and the bit more broadly hasn’t been able to solve the problem. Example topic sentence(s):

For a given application, both end-users and the original character designers may want to modify a character’s body shape or pose away from the predefined options. Currently, users have to manually edit or redraw all the accessory layers to fit the edited body.

• Flip the bit: Here you introduce your insight (i.e., your tool design) by flipping the bit. The topic sentence of this paragraph is the thesis statement for the entire paper. It should lay out the big idea that you’ll be pursuing. Spend this paragraph explaining your insight clearly, why it flips the bit that you set up, and what the implications of flipping that bit will be for the problem at hand. For the purposes of this assignment, it’s fine to assume that your bit flip will work out — we all know that research is iterative and projects will evolve. Example topic sentence:

The goal of our work is to make mix-and-match character creation tools more flexible by allowing users to modify a character’s body layers while automatically adapting the accessory layers to fit.

• Instantiate that bit flip in a solution: At this point, the reader understands the idea that you’re proposing, but it’s still very high level. In this paragraph, map that idea onto a concrete instantiation. This is where you introduce the tool you’ve built, and how it instantiates that insight. Example topic sentence:

Our approach is to automatically generate a rig, a set of constraints that specify how changes in the body layers should transfer to the accessory layers, for each accessory layer.

• Evaluate the solution: We haven’t discussed evaluation yet in the class, but a good introduction summarizes the evaluation that you performed to demonstrate that flipping the bit has the effects that you suspect. For the purposes of this assignment, ask yourself: how would you prove to a critical reader that flipping the bit has the effect you promised in solving the problem? We expect you to articulate what you will be manipulating and measuring, but we don’t require any actual results right now and we won’t hold you to this evaluation strategy — especially since sometimes your evaluation strategy evolves as your project evolves. Example topic sentence(s):

We use our approach to automatically rig a wide range of character accessories derived from existing mix-and-match data sets and show the results for various modifications to the shape and pose of the character. In addition, we demonstrate two applications where our rigs enable continuous edits that propagate to all the accessories: an interactive character customization interface where users modify various body shape parameters, and animations that change the body shape and pose over time.

From this outline of topic sentences, fill in the rest of the paragraphs. It’s fine to combine short paragraphs together, but the general problem-solution structure should be there.

Your introduction should be roughly 500-800 words long. You are welcome to include figures and citations in your introduction if they support your claims, but you are definitely not expected or required to.

Deliverables

• The PDF downloaded from Overleaf containing the introduction in the SIGCHI latex template should be submitted to Canvas.

---

Milestone 5: Wizard-of-Oz Prototype

Due 11:00am Weds, Nov 6.

At this point you’ve made a wireframe paper prototype of your most important goal. Hopefully you have iterated on your designs and ideas based off of initial feedback and in-class user tests. In this milestone, we’ll flesh out the full tool in Figma as well as plan metrics to gather during our in class evaluation on Weds, November 6. Your Wizard-of-Oz prototype should focus on breadth over depth (so show the range of all possible interactions, but it’s OK to have canned user inputs).

The learning goals of this milestone are to engage in the design process to have a working, high-fidelity WoZ prototype to test with your classmates.

Step 1: Breadth wireflow

While you now have a better idea of how one interaction works, it’s time to flesh out the full interaction for your tool. Before diving into Figma, I recommend discussing and agreeing as a group on flow-based wireframes (a wireflow) for your entire tool. Basically, take what you did for Milestone 3 but flesh out the wireflow for the other main user goals as well. Plan out how your tool works. What is the screen users see when they first open the tool? What are all the tasks you want to support, and how do users transition from one screen to another?

Example wireflow from Balsamiq

Put the low fidelity wireflow (you can do a paper sketch) and/or discussion notes in your ongoing design documentation.

Step 2: Visual design

What is the color palette of your tool? What fonts will you use? Do you want a logo (not required but encouraged if you want to use this project for a portfolio)? What visual branding, vibe, or aesthetic do you want to go for? What existing tools or apps should serve as visual inspiration for your tool? (Are they competitors in the same space, or something completely unrelated?)

While there is no required deliverable for this step, I recommend as a group you agree on the general aesthetics of the tool before you work on a Figma file together. If you decide to create a small brand identity visual guide (like below) reference file, include it in your ongoing design documentation.

Example brand identity visual guide for Muddy's Bake Shop (as a meta note, this page is an example of a good "portfolio" page for a rebranding case study if you want to get design based jobs!)

Step 3: Wizard-of-Oz prototype on Figma

First, if you haven’t already, sign up for a free educational account on Figma at https://www.figma.com/education/. One person should create the project workspace and invite all other members of your team to collaborate on editing the file.

Create the screens in your wireflow. For this assignment, it is recommended to make the frames their actual display size (e.g., desktop, tablet, or mobile screen sized based on your hardware). Remember we are going for a breadth prototype. This means:

• From the main home screen, all the buttons/navigation options should work
• However, when we click on a button, you can have “canned” user input (e.g., you only need to prototype out one scenario or one selected option per interaction)
• You do not have to combinatorically handle all user inputs (e.g., if you have a tool bar, not every tool bar options has to be clickable from every single screen). From the home screen, every tool bar option should be clickable, but once you set down the “user flow” for a specific task, you can just prototype out the relevant actions for said task. If users want to switch to a different task, it’s OK to ask them to go to the homepage and start the flow from there, as opposed to in the middle of another user flow.

On the right sidebar, Figma has a “Design” tab and a “Prototype” tab. Once you’re done with the designs, connect the screens together switching to “Prototype” mode. In prototype mode, you can click the blue + icons by your components and choose interactions from the drop down menu that appears, such as connecting frames together on click. To preview these newly formed interactions, press the play button on the upper right corner to go to Wizard-of-Oz prototype mode.

This prototype should be higher fidelity as it is the bridge between your design ideas and implementation. It should be specific and visual enough that an engineer could implement the UI from the Figma file alone.

As a warning, going from low to high fidelity prototyping takes a lot of time. Please start early; I would expect this Figma prototype to take around 10-20 hours total per group (split, hopefully, evenly between group members).

Resources

• Figma is a powerful design and prototyping tool with many built in resources and guides, such as this one on prototyping.
• Here’s an intro Figma Workshop by one of my undergraduate collaborators (press play to see the slides) which goes over app basics. In addition, he has taught an entire course on Figma if you want to learn more.
• Please don’t hesitate to stop by OH or shoot me a quick Slack message if you run into any Figma troubles.

Deliverables

On Canvas, 1 PDF that contains…

• A viewable link to your Figma prototype.
• We’re also going to be checking your design documentation to make sure you’ve been filling it out throughout the semester—so also a link to your “live” design documentation.
• The usual feedback paragraph: How long did your group spend on this assignment? Were there any unexpected challenges? How is the workload of the class matching to your expectations? How is the workload being distributed among the group and general group dynamic?

Rubric

While this assignment, like all other milestones, does not affect your final grade, I will be giving you feedback on these areas:

• Visual design: does the tool look “modern” and professional? How are the spacing, colors, iconography, and typography?
• Interaction design: can users easily accomplish their goals? Does the flow make sense? Is the tool discoverable? Are the controls visible and accurately mapped?
• Degree of agency: Does the tool have the potential for wide walls and diverse user inputs? (Note that the breadth based WoZ prototype does not actually have to accommodate wide walls–and in fact shouldn’t, as you should used predetermined responses–but the design itself should speak to user creative freedom.)

Milestone 6: System Diagram

Due 11:59pm Fri Nov 15.

The learning goals of this assignment are to prepare you for building out your tool for the rest of the semester. As such, this is a planning/reflection heavy assignment: you will reflect on what to iterate from your Figma prototype, you will plan out some libraries and function docstrings for your tool, and you will create a sample implementation timeline. I estimate this assignment will take roughly 10 hours total per group.

Step 0: Iteration

What did you learn from your in class WoZ evaluation and/or instructor feedback? What worked well, and what was confusing? Did you observe anything that was surprising?

In your ongoing design doc, write at least 3 main lessons learned as well as how you will change them going forward.

Step 1: State diagram

A FSM for a simple drawing tool that fades your strokes over time.

First, model your tool as a finite state machine with transitions. This can come pretty directly from your Figma, with separate screens or pop-ups each being a state, and button presses acting as transitions. You can make your system diagram in Figma, or Google Draw, or whatever tool feels best.

The FSM above is an example diagram for a very simple drawing tool that fades your strokes over time (10 seconds). The drawing tool also has the option to change your pen color and size. The dotted lines in the diagram represent the same transition to the state from the canvas with strokes state as the blank canvas state—basically, that users can download their image or change pen options in either state (to save visual clutter).

Paste this FSM diagram into a Google Doc, which you’ll add on to by answering the questions in step 2. The recommended deadline for this stage is by the EOD Monday November 11.

Step 2: Libraries & docstrings

Now that you have a high level view of your tool’s implementation, it’s time to figure out the code. In the Google Doc, answer these questions:

• I recommend you build your app in Javascript. What existing libraries are you using? Is there sample code you can find that you can build off of?
• What kinds of data structures will you be using, and to store what?
• How do you plan on storing the state of your tool, and transitioning to different states? E.g., will you use JS callback functions (like .onClick())? Does the library you’re using have some kind of state management system for you?

Next, write a list of function docstrings (inputs, outputs, and a brief sentence of what the function does) for your tool. Functions map nicely (but not necessarily perfectly) to the transitions in your FSM. Focus more on back-end functionality functions rather than front-end display functions. Let’s say we’re building the example tool above in P5.js. A few functions would be:

function penDown(color, strokeWeight) {
  /*
  draw a stroke with appropriate color and strokeWeight, and
  create a timer object and add it to the queue of timers.

  will go into the draw() loop in p5js.

  params: color, strokeWeight
  return: none
  FSM transition: "pen down"
  */
}

function decrementTimers(timers) {
  /*
  checks if framecount is divisible by 60 (a second has passed)
  and decrements each timer in the queue.

  will go into the draw() loop in p5js.

  params: timers (queue of timers)
  return: timers
  FSM state: canvas with strokes
  */
}


function timerExpired(timer, stroke) {
  /*
  removes associated stroke with expired timer.

  will go into the draw() loop in p5js.

  params: timers, stroke
  return: none
  FSM transition: "wait 10 seconds per stroke"
  */

function selectColor() {
  /*
  uses p5js's built in createColorPicker() in setup() to create
  a color picker; updates the color in draw()

  params: none
  return: color value
  FSM transition: "click pen color button"
  */
}

The more detailed you are in your state machine and docstrings, the easier your tool will be to implement. Use this assignment as an opportunity to ask and answer questions and unknowns.

Step 3: Timeline

Part of engineering a large system is setting shorter deadlines and goals along the way, as well as effectively divvying the work. Make a table in the Google doc as follows:

Task	Person(s)	Due

And fill it out. The first task is setting up your code repo (see Step 4 below). Other tasks include implementing the functions you listed above, iterating from in-class evaluations, and building front-end UI.

Some dates that may help you plan your timeline:

• November 20 is our next in-class evaluation of your tool’s MVP (minimum viable product). Basically, the core functionality of your tool should be built out, similar to what you identified for your low fidelity scenario paper prototype (the one you made a video of). Except this time, it’s a “depth” prototype since your tool should be able to accept diverse user inputs for a single task.
• December 2 is our final in class evaluation. All of the functionality of your tool should be completed by then, minus a few edge cases or UI tweaks.

Step 4: GitHub & bare minimum functionality

The first task in your timeline should be setting up the libraries and Github repo and making sure everyone can run the code on their personal computers and should be completed with this milestone submission. The second task should be to get some kind of bare minimum user interaction going that supports the core goal of your tool: uploading and displaying an image, creating one entry, etc.. Please record a very short screen grab showing your tool running locally with this bare minimum functionality.

As a reminder, you are more than welcome to use ChatGPT or other generative AI tools to help you with your implementation. If you prompt it to generate code for your bare minimum functionality in the library of your choice, what happens?

This is the last milestone before your final project is due. Use this chance to plan well so you can have a successful 3 weeks of development!

Deliverables

• On Canvas, a link to or PDF of your ongoing design documentation showing the iteration you plan to do after what your group learned from the WoZ evaluation.
• On Canvas, a PDF containing your system diagram, answers to part 2’s questions, functions, timeline, a link to a very short screen recording of your tool running with bare minimum functionality, and (optionally) any questions or concerns you have around technical feasibility.

---

Final Grading & Submission

Rubric

• 10% completed all the milestones on time
• 50% tool itself
• 40% communicating the tool
  • 25% written 4 page paper
  • 5% tool expo presentation
  • 5% PDF documentation
  • 5% video

Please also fill out the self and peer assessment form.

Final deliverables

The tool itself (50%)

Grading criteria include:

• Tool has polished interaction and visual design (e.g., your classmate wouldn’t point out a glaring error when using it)
• Tool accomplishes a range of tasks and handles diverse user inputs (wide walls)
• Tool attempts to meet group’s stated design goals
• Tool followed human-centered design cycle (e.g., group implemented feedback on various prototypes and iterated)
• Tool is accessible for the instructor to run on their computer and use (e.g., via visiting a web URL or having clear instructions on how to run the tool on localhost)

Make sure to include a link to the tool’s website or Github repo. If you choose to have a repo, and the repo is not public and you would like to keep it private, add my account (radiolarian) as a collaborator. But really the best solution, in terms of software development standards, is to remove your API keys and have a public repo :) Make sure your Github repo has a valid README that describes how to install and run the tool locally on your computer, including dependencies/libraries that need to be installed if they are not included already with the repo (e.g., aren’t covered by NPM or aren’t static .js files that already exist in the repo).

Written “research style” paper (25%)

Go back and edit your introduction in the SIGCHI Latex paper template. This short paper (4000-8000 words) should include:

• a short abstract (max 250 words)
• an introduction (~1 page)
• a methods/tool section (~1.5 pages), including figures showing your tool
• an evaluation section (0.5 pages)
• a short limitations/future work section (2 paragraphs)
• a short conclusion (1 paragraph)

For guidance on how to write a good short HCI paper, check out Catchy Titles Are Good: But Avoid Being Cute by Wobbrock. Also feel free to reference many of the papers we’ve read in class!

Abstract

An abstract is a summary of your work that focuses on two things: describing what was done and describing the results. Be specific about key findings. Generally, the sentence structure of an abstract is 1. motivation/problem 2. your solution 3. highlights of your solution 4. findings and implications of your solution.

Methods/tool section

This section answers the question, “what was done”? You should include:

• A paragraph describing your formative studies and how they lead to your design goals
• A paragraph summarizing your different design iterations to get to the final tool
• A paragraph that is a “tool walkthrough” describing how a potential user would use the tool and describing its features
• A pargraph describing how the tool was implemented, e.g., what libraries did you use, any stand out development insights or challenges
• At least 1 figure of your tool, ideally showing multiple states
• Optionally, figures of earlier designs (like your wireflow or Figma) to be referenced during the design iteration paragraph

Evaluation

This section answers the question, “now that the tool exists, so what?” You should write about how you met (or failed to meet–failure is OK!) your design goals. Include:

• A paragraph explaining your evaluation procedure (e.g., how many participants, what metrics did you collect, what tasks you had the participants do)
• A paragraph providing evidence to back up meeting your design goals. These could be qualitative (user quotes) or quantitative (small tracking measurements or likert scales) data. No need to do statistical analysis, painting a general picture is fine–but be sure to not make grand claims you cannot back up.

Limitations / Future work

This section should include two paragraphs:

• A paragraph on limitations of your tool. We can’t solve every problem in an 8 week class project. What didn’t you get to? What didn’t work as well as you had thought?
• Also touch on this specific point: going back to our in class discussions on power and art, do you feel like your tool meaningfully addresses new ways of art making, or challenges normative power dynamics? Why or why not?
• A paragraph on future work. If you had all the time in the world, what would you like to add?

Conclusion

The conclusion is an abstract inverted: I personally like flipping the sentence order of my abstract and ending the conclusion with a big “implications” sentence. What kind of future do you hope to see through designing and developing this tool?

Optional extra credit: Round out your paper with a related works section for a potential of +3% more points for this assignment section. If you would like to pursue this option, please contact the instructor and stop by office hourse.

In-class presentation (5%)

You will have an 8 min presentation with 3 minutes of Q&A during our last class (Weds, Dec 4). Attendance is mandatory. You should use presentation slides. The presentation should address (with suggested time allocations):

• Motivation for your tool, your needfinding results, your design goals (2 min)
• A brief walkthrough of your design process and iteration (1.5 min)
• An interactive demo of your object (you may ask the class audience for inputs) (3.5 min)
• Your evaluation results (0.5 min)
• Any limitations or future work (0.5 min)

Grading criteria include:

• Is the presentation clear and concise? Does it paint not only a good picture of the tool’s process, but also showcase the depth and diversity of the tool itself?
• Do the presentation slides address the points above?
• Did the presentation stay under 8 minutes?
• Did the team participate equally in the presentation, answer questions well, and ask thoughtful questions to others?

PDF design documentation (5%)

You’ve been adding to this all semester. Grading criteria include:

• Inclusion of design goals, in-class evaluation notes, low fidelity wireframes, other prototypes, etc.
• Inclusion of design decision rationale for any pivots made in your design or development.

Extra credit opportunity: clean up your design documentation (at the level of this could be a PDF for your design portfolio, put some work into the visual design and presentation and communication of the information, rather than sproadic Google Doc notes) for an additional +2% points in this category. As an example of what a “clean” design would look like, you can see my write up for Adshirt.

Video (5%)

This should be a short (~3 minute) video that standalone explains your tool. Imagine the video as the first thing people see on your portfolio webpage piece for the tool. The video should

• Open with at least 2 sentences around the motivation and context for the problem your tool solves
• Talk briefly about your design goals and design process/decisions/iteration
• Shows a narrated screen recording of your tool working, to demonstrate its floor, ceiling, and walls. Make sure you show every feature!
• Talk briefly about how you evaluated the tool and your results

You can largely reuse your presentation materials for the video! Grading criteria is the inclusion of the points above, and also how “polished” the video is (e.g., good audio balancing, editing, etc.)

Everyone in the group should get the same grade, but these grades can potentially vary ~±5% based off of peer and self assessment. Link to form: https://forms.gle/HxK6Qbg9UaSfoxUN9

1. Students may work in groups of 3 if necessary at instructor’s discretion. Groups may also be smaller (e.g., 2 or alone) but it is highly discouraged since this project’s workload is scoped to be done in a group. If this is something that still appeals to you, please email the instructor a few paragraphs justifying why you want to work alone/in a pair. ↩
